Commercial Lid Type Dishwasher
video
Commercial Lid Type Dishwasher

Commercial Lid Type Dishwasher

Product Description Meet our Commercial Lid Type Dishwasher, a smart choice for school, hotel, and cafeteria kitchens, renowned for its exceptional water efficiency and user-friendly operation. Constructed entirely from food-grade 304 stainless steel, it consumes only 1.8 liters of water per...

Description

Technical specifications





Specification Category

Details

Product Name

Electric Catering Oven

Product Series

SM(SM2-901C,SM2-521H,SM2-522H,SM2-523H)

Number of Tiers

1/2/3

Number of Baking Trays

SM2-901C:One layer, one tray

SM2-521H:One layer, two trays

SM2-522H:Two layers, four trays

SM2-523H:Three layers, six trays

Max Temperature

280℃

Min Temperature

Room temperature

Exterior Dimensions(w*d*h)

780*1015*300/1320*1090*1050/1320*1090*1470/1320*1090*1710mm

Interior Dimensions(w*d*h)

420*620*150/900*720*230/900*720*230/900*720*230mm

Power Type

Electric

Electric Connection Load

2.8/5.5/11/16.5kW

Electric Connection

220V/50Hz(SM2-901C),380V/50Hz(SM2-521H,SM2-522H,SM2-523H)

Baking Tray Size

40*60 cm

Optional

Steam bag, exhaust hood, stone slab

Surface Material

Stainless steel plate + aluminum plate

Transport Package

Carton Box / Wooden

Applicable Occasion

Bakeries, fast food restaurants, pizza shops;Restaurant;Dance Hall

Origin

Wuxi City,Jiangsu Province,China



Product Description





Meet our Commercial Lid Type Dishwasher, a smart choice for school, hotel, and cafeteria kitchens, renowned for its exceptional water efficiency and user-friendly operation. Constructed entirely from food-grade 304 stainless steel, it consumes only 1.8 liters of water per rack while delivering an 82-90°C sanitizing rinse. Ideally suited for venues serving 100-300 meals, it achieves thorough cleanliness and remarkable savings even in compact spaces.Full-cycle washing temperatures are precisely controlled - the wash stage operates at 50–60°C for effective grease removal, while the final sanitizing rinse at 82–90°C delivers powerful bacteria elimination. This dual-temperature control ensures every batch meets commercial hygiene standards.





Technical specifications



Specification Category

Details

Product Name

Commercial Lid Type Dishwasher

Type

Dishwasher

Certification

CE, ISO, CCC

Exterior Dimensions

713×748×1445mm

Cleaning Temperature

50~60 ℃

Spray Temperature

80~90 ℃

Voltage

380V 3N~/50Hz

Total Power

14.7kw

Washing Volume

60 baskets/hour (adjustable)

Distributor

External

Single Basket Water Consumption

2L

Product Features

Cleaning, drying, disinfecting

Suitable Venue

Suitable for venues with 100-300 people.

Transport Package

Carton Box / Wooden

Applicable Occasion

Kitchen;Cafeteria; Dining Hall;Restaurant;School

Origin

Hangzhou,China

Our Advantages







Ultra-Water-Saving Design + High-Efficiency Washing Capacity

Advantage: Consumes only 1.8 liters of water per rack with an optimized water circulation system for maximum cleaning efficiency. Wash temperature 50–60°C effectively breaks down grease, while the final sanitizing rinse at 82–90°C eliminates common bacteria. Maximum washing capacity reaches up to 60 racks per hour, with a complete cycle of approximately 90–120 seconds per rack (including wash, rinse, and drain stages).

Benefit: Delivers hygienic tableware while significantly reducing water costs. Efficient throughput easily handles peak-hour demands, making it ideal for medium-scale operations that prioritize both long-term cost optimization and washing performance.




High-Temp Sanitizing Rinse

Advantage: The final rinse utilizes 82-90°C water to eliminate grease and sanitize effectively.

Benefit: Guarantees spotlessly clean tableware and provides reliable hygienic safety, giving peace of mind to both you and your customers.




Assisted-Lift Spring for Easy Opening

Advantage: Integrated high-tension springs provide effective counterbalance for the heavy lid.

Benefit: Allows effortless one-handed opening and closing, significantly reducing operator fatigue and improving workflow efficiency




All-Stainless Steel Build + Double-Layer Door Insulation + Corrosion-Resistant Wash Pump

Advantage: Both interior and exterior are constructed from food-grade 304 stainless steel for corrosion resistance and easy cleaning. The double-layer door design with built-in insulation effectively reduces heat loss while minimizing operational noise. The stainless steel wash pump withstands high temperatures and corrosion, delivering stable performance even under long-term, high-frequency use.

Benefit: The double-layer door minimizes thermal energy loss, and combined with the optimized water circulation system, further reduces energy consumption per rack - delivering exceptional water and energy savings especially under high-frequency operation. The stainless steel pump offers extended service life and low failure rates, significantly reducing maintenance frequency and long-term operating costs.

This dishwasher is a perfect balance of space efficiency and performance:

Primary Applications

School cafeterias, corporate canteens, boutique hotels, and resorts.

Extended Applications

Mid-sized restaurants, nursing homes, healthcare facility kitchens, and any venue requiring efficient batch washing.

product-800-800

We are committed to providing reliable equipment and worry-free support.

product-800-800

Our Service

Professional installation guidance and responsive after-sales service are available.

Warranty

he unit comes with a 1-year comprehensive warranty, with extended coverage on core components.





Product Display


product-800-800
product-800-800


There are 4 models which can be option:

product-800-800
Single-Pump Model
product-800-800
Dual-Pump Model
product-800-800
Single-Pump Model with Full Workstation Set
product-800-800
Dual-Pump Model with Full Workstation Set





Details display



product-790-1345

product-790-1139

product-790-1165

product-790-1345

product-790-1639

product-790-1154



product-1-1product-15-15

product-790-1041

product-790-769













Production Process





12

13


product-1000-974




Packaging and Transportation


product-800-450
product-800-450



Our Certificate





p202507171741321fdb7

18

19

20



FAQ

Q: What is its washing speed?

A: As a batch-type washer, each complete cycle takes approximately 90-120 seconds per rack. It is ideal for medium-scale operations that prioritize water/space savings over continuous conveyor-line speed.

Q: Can it really clean effectively with only 1.8L of water?

A: Absolutely. The machine uses a high-pressure spray arm to create powerful water jets that, combined with high temperature, efficiently remove grease. The small volume of water is highly recycled, guaranteeing excellent cleaning results.

Q: Is the lid heavy and safe to operate?

A: The built-in assisted-lift spring makes opening remarkably easy. The lid is also designed for safety and stability, ensuring secure and reliable operation.
